5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder

5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder

  • 5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder
  • 5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder
  • 5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder
  • 5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder
5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder
Product Details:
Place of Origin: JIANGSU CHINA
Brand Name: SNYNXN
Certification: CE ISO GMP
Model Number: GLP-5
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotaible
Packaging Details: Film Wrapping, Wooden Case.
Delivery Time: within 60 days
Payment Terms: T/T, L/C
Supply Ability: 100 set/year
Contact Now
Detailed Product Description
Type: Mini Spray Dryer Raw Material: Raw Liquid
Working Process: Continuous Evaporation Capacity: Max. 5 (kg/h)
Nozzle Diameter: 1mm Spray System: Two- Fluid Nozzle (0.75/1.0/1.5/2.0/2.5mm)
Special Design: Corrosive / Explosive / Wall Adhesive Way To Discharge: Touch Screen / Remote / Button
Key Selling Points: Long Service Life Dimension(L*W*H): 940*850*1500mm
High Light:

Stainless Steel laboratory spray dryer

,

Mini laboratory spray dryer

,

raw liquid spray dryer milk powder

Description: Mini Spray Dryer

Stainless Steel Mini Laboratory Spray Dryer For Making Milk Powder Price

Experimental stainless steel Spray Dryer is also called spray drying machine; spray dryer is used for small industrial production purpose or for doing experiment, for lab; big type spray dryer is for mass industrial production of milk powder, protein, blood, chemical, herbal extract, etc

This Stainless steel mini laboratory spray drye Equipment is mainly suitable for laboratory for changing liquid material directly into micro powder, without filtration, concentration and smash before drying, the supplies for all solution is a broad applicability, such as emulsion, suspending liquid.
Especially the stainless steel mini spray dryer has been widely used in the food and pharmaceutical industry due to its corrosion resistance, better thermal conductivity and higher efficiency advantages.

Technical Data:

Item / Model (GLP)
5
25
50
100
150
200
500
800
1000
Inlet temperature (℃))
140-350 Automation
Outlet temperature (℃))
80-90
Spray pattern
High speed centrifugal atomizer (mechanical drive/stepless frequency control to choose)
Water evaporation (kg / h)
5
25
50
100
150
200
500
800
1000
Atomizer speed (rpm)
25000
22000
21500
18000
16000
13000
12000
Atomizing disc diameter (mm)
60
120
150
180-210
Electric heating maximum power (kw)
8
31.5
60
81
99
Equipped with other heat sources
Powder recovery (%)
about 95% more
Covering length (m)
1.6
4
4.5
5.2
7
7.5
12.5
13.5
14.5
Covering width (m)
1.1
2.7
2.8
3.5
5.5
6
8
12
14
Tower height (m)
1.75
4.5
5.5
6.7
7.2
8
10
11
15
Nozzle lifting height (m)
- -
2.5
2.5
3.2
3.2
3.2
3.2
3.2
3.2
Note: The above data for reference only. Moisture evaporation and material properties, solid content and the hot air inlet temperature. Users can select the heating mode according to the local energy situation, select the collecting, dedusting method according to the material characteristics.

5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder 0

5kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder 15kg/H Stainless Steel Mini Laboratory Spray Dryer Machine For Milk Powder 2

FAQ

Q: Are you trading company or manufacturer ?What about your after-sale service?
A: We are machine manufacturer. And we offer the before and after service. First,we can offer the lab or sample for you.Then inspection in my company, empty operation then export. And our engineer will stay on site to do installation. Once broken, our person will arrive in 72 hours. Any spare parts broken, we will express in 12 hours.

Q: How long is your delivery time?
A: Generally speaking it is 10-20 days if the goods are in stock. or it is 30-45 days to make the machines based on your request.

Q: What is the minimum order quantity?
A: For our machines,you can make order based on your purchase schedule.Just only one set is welcome.

Q: What is your terms of payment?
A: Payment<10000USD, 100% in advance. Payment>10000USD, 30% T/T in advance, balance before shippment.
