Specializing in the production of pharmaceutical machinery and granulating drying equipment.

|
| Place of Origin: | JIANGSU CHINA |
| Brand Name: | SNYNXN |
| Certification: | CE ISO GMP |
| Model Number: | CT-6 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Packing in Wooden case |
| Delivery Time: | IN 30 DAYS |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 sets / year |
| Type: | Hot Air Circulating Drying Oven | Drying Process: | Continuous Automatic Drying |
|---|---|---|---|
| Capacity: | 100-2000 Kg/batch | Heating Source: | Steam+electricity |
| Range Of Temperature: | 20-160 (adjustable) | Power: | 0.5kw-65kw |
| Key Selling Points: | Long Term Sustainable | Machinery Test Report:: | Available |
| Voltage: | 380v Or 220v Or As Consumer Request | After-sales Service Provided: | Online Support, Field Maintenance And Repair Service |
| High Light: | 160C hot air oven drying,Tray hot air oven drying,Available Green tea drying machine |
||
Tray Dryer Oven Hot Air Circulating Drying Oven Industrial For Fruit Green tea moringa leaf vegetables
The drying process is an important link that affects the quality and economic value of Chinese medicinal materials. The drying effect directly affects the use, quality and appearance of the product. Harvested Chinese herbal medicines and Chinese herbal medicines. Except for a few kinds that can be used for fresh medicinal purposes, most of them need to be dried and processed for storage. "All medicines should be stored with caution, such as drying in the shade, drying out, and drying without being fully wet, it will inevitably lead to corrosion, mildew, and decay."
Herbal Extrac Circulating Drying Oven uses a low noise and high temperature proof axial flow blower and an automatic temperature control system. The whole circulation system is the fully enclosed to make that the heat efficiency of the drying oven increases from 3-7% of the traditional drying oven to 35-45% of the present one. The highest heat efficiency can reach 50%.
Technical Parameter
No. | Model | Field standard model | Technical parameter | ||||||||
| Evaporate d area (m3) | Effective volume (m3) | Drying capacity (kg/batch) | radiator area(m3) | Steam consumption on(kg/h) | Electrical Heater power(kw) | Fan volume (m3/h) | Fan power (kw) | ||||
| 1 | CT-C-O | RXH-7-C | 7.1 | 1.3 | 60 | 15 | 15 | 6-9 | 4510 | 0.45 | |
| 2 | CT-C-I | R×H-14-C | 14.1 | 2.6 | 120 | 23 | 20 | 15 | 4510 | 0.45 | |
| 3 | CT-C-II | R×H-27-C | 28.3 | 4.9 | 240 | 48 | 40 | 30 | 9020 | 0.45×2 | |
| 4 | CT-C-IIA | R×H-27-C | 28.3 | 4.9 | 240 | 48 | 40 | 30 | 9020 | 0.45×2 | |
| 5 | CT-C-III | R×H-41-C | 42.4 | 7.4 | 360 | 72 | 60 | 45 | 13530 | 0.45×3 | |
| 6 | CT-C-IIIA | R×H-41-C | 42.4 | 7.4 | 360 | 72 | 60 | 45 | 13530 | 0.45×3 | |
| 7 | CT-C-IV | R×H-54-C | 56.5 | 10.3 | 480 | 96 | 80 | 60 | 18040 | 0.45×4 | |
| 8 | CT-I | R×H-14-B | 14.1 | 2.6 | 120 | 23 | 20 | 15 | 1414 | 1.1 | |
| 9 | CT-II | R×H-27-B | 28.3 | 4.9 | 240 | 48 | 40 | 30 | 5230 | 1.1 | |
| 10 | CT-III | R×H-41-B | 42.4 | 7.4 | 360 | 72 | 60 | 45 | 9800 | 2.2 | |
| 11 | CT-IV | R×H-54-B | 56.5 | 10.3 | 480 | 96 | 80 | 60 | 9800 | 2.2 | |
Showcase:
We are professional supplier for several years in China for furnace and components.
Our advantages are as below:
1.Hight quality, excellent technician. good team work;
2.OEM service.
3.Factory wholesale price.
4.Polyfoam filled inside the furnace and wooden carton package outside.
5.One year quality warranty for whole furnace/oven.
Start from 2007, SNYNXN is a professional manufacturer for Industrial Drying and Granulation equipment like Fluid Bed Dryer, Mixing Granulating Machine, vacuum oven and Grinding Machine, Mixing Machines and etc.
welcome to visit our company!
