Specializing in the production of pharmaceutical machinery and granulating drying equipment.

|
| Place of Origin: | JIANGSU CHINA |
| Brand Name: | SNYNXN |
| Certification: | CE ISO GMP |
| Model Number: | SYH 200 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Export Packing in Wooden case |
| Delivery Time: | IN 30 DAYS |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 sets / year |
| Type: | SYH 3D Swing Mixing Machine | Application Scope: | Chemical Cosmetic Pharmacy Food Industry |
|---|---|---|---|
| Usage: | Mixing Powder/ Granules | Max. Loading Volume: | 1 -1500 L, Customized. |
| Max. Feeding Weight: | 50~1500 KGS/batch | Discharge: | Bottom, Butterfly Valve |
| Key Selling Points: | High-accuracy, High Uniformity | Dimension(L*W*H): | According To The Model |
| Voltage: | 220V/380V, According To Customer Needs | After Sales Service: | Online Support, Engineers Available To Service Machinery Overseas |
| Highlight: | Blender Multi Direction Mixer,Planetary Multi Direction Mixer,1500KGS/batch Dry Powder Mixing Machine |
||
1.Features
The barrel for charging the materials is driven by the driving shaft. The barrel body carries on the repeated level movement, rotation, turning and other complex movements so that the materials will carry out the three dimensional and complex movements along the barrel body so as to realize the various movements of the materials. Through disseminating, gathering, agglomerating and mixing to realize uniform mixing.
2.Applications
The mixing barrel of the machine moves in multi-direction. For the materials, there is no centrifugal function, without the specific gravity segregation and the layer division. For each of build-up phenomenon, there is the remarkable weight rate.
The mixing rate is up to 100%.The machine id the desired product in various mixers at present.
The material charge rate of barrel is big. Maximum rate can be up to 90%(the normal mixer has only 40% charge rate.). It is high in efficiency and short in the mixing time.
The barrel adopts arc shape connections and its well polished.
The machine is used for mixing the powder state and grain state materials with the high uniformity in the pharmaceutical, chemical, food, light-industry, electronic, mechanical, metallurgical, nation defense industries and other science and technology institutes.
|
Model
|
Mixing
Barrel
Volume
(L)
|
Maximum
Loading
Coefficient
(%)
|
Maximum
Material
Load (kg)
|
Voltage
(V.Hz)
|
Total
Power
(Kw)
|
Speed
(rpm)
|
Weight
(kg)
|
|
SYH-2
|
2
|
80
|
0.8
|
380/50
|
0.18
|
2-12
|
15
|
|
SYH-17
|
17
|
80
|
6.8
|
380/50
|
0.75
|
2-12
|
80
|
|
SYH-30
|
30
|
80
|
12
|
380/50
|
0.75
|
2-12
|
90
|
|
SYH-60
|
60
|
80
|
24
|
380/50
|
1.1
|
2-12
|
150
|
|
SYH-100
|
100
|
80
|
40
|
380/50
|
1.5
|
2-12
|
220
|
|
SYH-200
|
200
|
80
|
80
|
380/50
|
2.2
|
2-8
|
400
|
|
SYH-400
|
400
|
80
|
160
|
380/50
|
4
|
2-8
|
500
|
|
SYH-500
|
500
|
80
|
200
|
380/50
|
5.5
|
2-8
|
750
|
|
SYH-600
|
600
|
80
|
240
|
380/50
|
5.5
|
2-8
|
900
|
|
SYH-800
|
800
|
80
|
320
|
380/50
|
7.5
|
2-8
|
1100
|
|
SYH-1000
|
1000
|
80
|
400
|
380/50
|
7.5
|
2-8
|
1200
|
|
SYH-1500
|
1500
|
80
|
600
|
380/50
|
11
|
2-8
|
1500
|
|
SYH-2000
|
2000
|
80
|
800
|
380/50
|
15
|
2-8
|
1700
|
